Red Phase Instruments, an Australian Manufacturer

For over 35 years Red Phase Instruments have been at the forefront in the design and manufacture of test equipment used to investigate the operational integrity of utility supply and metering systems.

In over 30 countries our reputation is synonymous with quality and reliability, with some of our products still in service with utilities around the world after 20 years of operation.

Red Phase Instruments is a trusted tier one supplier to the Power Industry, utilities, engineers and maintenance personnel on 5 continents. With a commitment to research and development of innovative and lasting solutions we expect to remain the preferred test equipment provider for the next 35 years.

Please browse through our product list on the left of the screen.


590G-V2 CT TESTER
Since 1999, Red Phase Instruments has led the way in the manufacture of portable CT error testing equipment. Our portable analysis method has allowed utilities around the world to test their metering CTs easier and faster than using bulky traditional methods without jeopardizing accuracy. Following feedback from our users, our Model 590G-V2 is the latest version of this successful and well proven CT error tester. The 590G-V2 has all the features and advantages of the previous models with additional testing features, better accuracy and smaller size and weight. In a world where cost control is gaining importance, this CT tester not only lowers testing costs by being simple, fool-proof and fast. It also allows utilities to pursue the very important (yet at many times forgotten) task of testing installed CTs for detecting tampering, and minimizing losses due to faults. Test capabilities: Offline CT Ratio and phase error measurements. CT 1.6 kHz Admittance test. Graphical plot of CT excitation curve. CT and PT Burden test. Measurement of CT winding resistance. CT polarity measurement. PT full load simulated tests (with 590D-1 accessory) Live Live CT testing (with 590F accessory) Download Product Brochure To find out more please go to the Instrument Transformer Testing link in the product list on the left of the screen.
590K CAPACITOR VOLTAGE TRANSFORMER TESTER
Features: 0.05% Ratio accuracy - under rated voltage and load conditions Truly portable ~ 20kg. Empirical database - almost 60 characterized CVT's from over 12 manufacturers stored in memory. also..... Tests at any VA and Power Factor. Test CVTs rated to 500kV. The Red Phase 590K has no equal in the portable CVT measurement class, of this we are certain. The 590K is the result of 4 years of intense research into the development of the most accurate portable CVT analyzer on the planet. Using highly complex software modeling combined with specialized Digital Signal Processing and advanced computer hardware, the 590K has the ability to characterize even unknown CVT models to a ratio error of just 0.25% worst case but most CVT's to 0.05%. Download Product Brochure To find out more please go to the Instrument Transformer Testing link in the product list on the left of the screen.
